5G Outdoor CPE

Item No.: XGC5552
XGC5552 is a high-performance 5G outdoor CPE, which supports various 4G/5G spectrums and ultra high speed, and has built-in high-gain directional antennas to expand signal coverage.it has waterproof and lightning protection design.
  • Chip platformQualcomm SDX55
  • Size209*109*99.5mm
  • Weight810g
  • Quantity
    -
    +
    Description Parameters
    Description

    SmileMbb 5G Outdoor CPE

    3.5Gbps Download Rate | Poe Power Supply | 2.5 Gigabit LAN Port


    SmileMbb 5G Outdoor CPE

    Qualcomm SDX55 Platform

    Support 5G SA/NSA , LTE/WCDMA Global Cellular Bands


    Qualcomm SDX55 Platform,Support 5G SA/NSA

    Smart Antenna Technology, Powerful Performance

    Thanks to the 5G SRS  Antenna Switching by 4 antennas,5G Outdoor CPE detects the signal in real time to provide you
    with reliable performance even when encountering interference.




    Compact Size, Simple Installation

    SmileMbb 5G Outdoor CPE Provides pole-mounted installation, it is also toughly built to
    withstand all kinds of weather conditions, rain or shine.


    Compact Size, Simple Installation

    5G Outdoor CPE for Better Wireless Signal

    SmileMbb 5G Outdoor CPE  features outdoor installation, which makes it easier to receive 5G signal,
    even in remote regions where 5G signal is weak.


    5G Outdoor CPE for Better Wireless Signal

    Multi-Scenario 5G Application

    Equipped with a 2.5Gigabit Ethernet port, 5G outdoor CPE can be connected to
    a host of devices with Ethernet cables, making it possible to be applied in varied scenarios.


    Parameters


    Technical parameter

    chip platform

    Qualcomm SDX55

    Network Mode

    NSA&SA

    Frequent band

    5G NR: n1/n3/n5/n7/n8/n20/n28/n38/n41/n77/n78/n79
    FDD-LTE: B1/B2/B3/B5/B7/B8/B20/B25/B28/B32

    TDD-LTE: B34/B38/B39/B40/B41/B42

    WCDMA: B1/2/5/8

    Protocol Version

    3GPP Release 15

    MIMO for wireless

    5G SUB6G+LTE Support  4*4MIMO

    5G+LTE EN-DC

    Peak Data Rate

    5G Sub6G DL Peak Data Rate  :100MHZ+256QAM+4*4MIMO: 1.43Gbps
    LTE FDD CAT20 DL  Peak Data Rate:256QAM+5CA+4*4MIMO:2.0Gbps
    LTE+5G EN-DC can up to 3.43Gbps

    Wi-Fi Standard

    802.11a/b/g/n

    2.4GHz 1*1MIMO : 150Mbps

    Size

    209*109*99.5mm

    Weight

    810g

    Power supply

    POE (48V/0.5A)

    Physical interface

    1*2.5Gibabit WAN/LAN RJ45 Port

    1*1.8V&3V 4FF (U)SIM

    1*POE RJ45 Port

    LED

    5G Network,4G Network, WIFI,

    Button

    Power,Reset

    Characteristic

    VPN Pass-Through Support (PPTP, L2TP & IPSec), Firewall,

    Local & Remote management


    Interface of XGC5552
